Specifications
1 2
Dimensions:
Weight:
Design:
Power Handling:
Nominal Impedance:
Frequency Response:
Sensitivity:
Maximum Short term SPL:
Connection:
605mm x 270mm x 156mm
(23
4/5
” x 10
3/5
” x 6
1/10
”)
9.2Kg (20
6/25
lbs)
Ported, acoustic bandpass with built in
protection circuit
150W continuous
4 Ohms
39Hz - 140Hz (+/-6dB) 18dB/ octave
band-pass
86dB 1m/1W *
108dB 1m/1W **
3-Way binding post
* Corrected nearfield port measurement.
** Corrected nearfield port measurement. Assumes no in-room boundary loading which in some cases
may increase SPL by as much as 6dB.
Limited Warranty:
The ALF80 is designed to operate reliably for many years. Correctly installed and in accordance with
these instructions, Amina warranties the ALF80 against defective materials and workmanship for a
period of one year.
