Wireless Indoor Horn
Specifications
Mounting Instructions
Dimensions: ...................................10"h x 7"w x 6"d
Weight: .............................................4.5 lbs.
Power options: ................................120vac-240vac, 0.07A, 50-60 Hz (hard wired)
Operating temperature: .................14˚-140˚F (-10˚-60˚C)
Humidity: .........................................0%-95% non-condensing
Bell volume:.....................................78-103 dB
Receiver frequency: .......................450-470 MHz (factory set)
Paging format: ................................POCSAG, narrow band
Data baud rate: ...............................512 BPS
Receiver sensitivity: .......................10uV/M
Channel spacing: ............................12.5 KHz
2
7.089”
10.040”
1.812” 1.563”
1.188”
2.280”
6.435”
9.387”
The Wireless Indoor Horn may be easily
mounted to a wall using the six keyhole
openings on the back of the enclosure.
Mounting screws not provided.
4.553”
7.091”
10.043”
