OWNER’S MANUAL
PARTS LIST
FAS-3C
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 19 of this manual.
KEY
PART NO.
NO.
FAS-3C
DESCRIPTION
QTY.
1
L98409-04
Cabinet Assembly
1
2
L98006-02
Front Panel Assembly
1
3
L98410-04
Reflector Unit
1
4
L98103-03
Burner Assembly
1
5
L98135-03
Thermostat Valve Assembly
1
6
L99066-01
Thermostat Valve Base
1
7
L98084-01
Self Tapping Screw
2
8
L98085-01
Mounting Bracket
1
9
L98133-04
Thermostat Outlet Tube Assembly
1
10
L98055-01
4-Way Connector
1
11
L98056-01
4-Way Connector Bracket
1
12
L98057-01
4-Way Connector Fixed Nut
1
13
L98411-01
Ignitor Line
1
14
L98071-03
ODS Pilot
1
14-1
098514-01
Thermocouple
1
14-2
L98071-07
Ignitor Electrode
1
15
L98072-01
ODS Mounting Bracket
1
16
L98817-01
Self Tapping Screw
7
17
L98124-04
Valve to Regulator Gas Line Assembly
1
18
L98914-01
Pilot Regulator Assembly
1
19
L98125-04
Regulator to ODS Line Assembly
1
20
L98117-04
“A” Burner Gas Line Assembly
1
21
L98120-04
“B” Burner Gas Line Assembly
1
22
L98122-04
“C” Burner Gas Line Assembly
1
23
L99023-01
Injector
3
24
L98115-08
Main Inlet Tube Assembly
1
25
L99029-05
Pressure Regulator
1
26
L98801-01
Washer
2
27
L98806-01
Self Tapping Screw
2
28
L98010-04
Grill Guard
1
29
L98011-01
Grill Fastener
2
PARTS AVAILABLE - NOT SHOWN
100642-01
Hardware Assembly
1
104892-44
CSA/AGA Decal
1
L98098-01
Gas Instruction Decal
1
L98100-01
Inside Warning Label
1
L98080-02
Thermostat Sensing Bulb Clip
2
