OWNER’S MANUAL
PARTS LIST
FA-3B
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 19 of this manual.
KEY PART NO.
NO. FA-3B DESCRIPTION QTY.
1 L98409-02 Cabinet Assembly 1
2 L98005-02 Lower Front Panel Assembly 1
3 L98410-02 Deflector Unit 1
4 L98103-03 Burner Assembly 1
5 L98071-01 ODS Pilot Assembly 1
5-1 098514-01 Thermocouple 1
5-2 L98071-07 Ignitor Electrode 1
6 L98072-01 ODS Mounting Bracket 1
7 L98817-01 Self Tapping Screw 7
8 L98034-01 Control Valve 1
9 L98411-01 Ignitor Line 1
10 L98028-01 Control Valve Bracket 1
11 L98054-01 Control Valve Fixed Nut 1
12 L98059-01 Control Valve Main Inlet Nut 1
13 L98115-02 Main Inlet Tube Assembly 1
14 L98124-02 Valve to Regulator Line Assembly 1
15 L98914-01 Pilot Regulator Assembly 1
16 L98125-02 Regulator to ODS Line Assembly 1
17 L98117-02 Burner Gas Line Assembly A 1
18 L98120-02 Burner Gas Line Assembly B 1
19 L98122-02 Burner Gas Line Assembly C 1
20 L99023-01 Injector 3
21 L98061-01 Control Knob 1
22 L98906-01 Control Rod Assembly 1
23 L99029-01 Pressure Regulator 1
24 L98801-01 Washer 2
25 L98806-01 Self Tapping Screw 2
26 L98010-02 Grill Guard 1
27 L98011-01 Grill Fastener 2
28 L98085-01 Mounting Bracket 1
PARTS AVAILABLE - NOT SHOWN
100642-01 Hardware Assembly 1
104892-39 CSA/AGA Decal 1
L98098-01 Gas Instruction Decal 1
L98100-01 Inside Warning Label 1
