Parts Diagram / List - Viewing Door

1

26347

Painted, Feed Door (40579)

1

2

69901MB Painted, Fascia-Deluxe Door

1

3

83566

#8-32 Kep Nut

4

4

88082

3/4 Round Rope Gasket-Blk

4.3

5

89284

Silicone Sealant (Black) (10.1 Oz)

0.9

6

891979

Door Glass

1

7

25904

Clip, Glass

3

8

25905

Air Wash Plate

1

9

83278

7/32 Id X 1/2 Od X 3/64 Fl W

3

10

83202

10-24 X 3/8 Ph Pn Hd Ms

6

11

C-D-040

Door Handle

1

12

83547

Washer, 11/32"Id X 11/16" Od X 1/16 Thk

4

13

83903

Spring

1

14

83546

5/16-18 Jam Nut

1

15

C-S-4080 Door Handle Cam

1

16

83338

5/16-18 Lock Nut

1

17

88174

Gasket - Flat, Glass (3/16T X 3/8W)

3

Key

Part No.

Description

Qty.
