Page 25
25
Parts List
1
69846
Door Assembly
1
2
40571
Hinge Block
2
N/S
83576
3/8-24 Jam Nut
2
3
83575
Hinge Pin
2
4
69671
Ash Pan
1
5
891987
Ash Pan Latch
2
6
86625
Housing Assy, Burn pot
1
7
86624
Burn pot Assembly
1
8
891194
Cleanout, Ash
2
9
86630
Weldment, Top Lid
1
10
891148
Handle, Plastic
1
11
891980
Cabinet Side, Left
1
12
891193
Cabinet Side, Right
1
13
891398
Hopper Assembly
1
14
80491
Microswitch
1
15
83541
#4-40 Bolt
2
16
83542
#4-40 Lock Nut
2
N/S
80493
Extension Wiring Harness
1
17
891191
Access Panel
1
18
80461
Power Supply Cord
1
19
80462
Power Receptacle
1
20
88119
Insulation, Blanket
1
21
891164
Weldment Auger Housing
1
22
891141
Auger
1
-
69513
Assy., Top Bushing
(Includes items 23-25)
1
23
891189
Top Bushing Plate
1
24
891132
Bushing
2
25
83534
Retaining Ring
2
-
69514
Assy., Bottom Bushing
(Includes items 26, 24, 25)
1
26
891190
Bottom Bushing Plate
1
27
891180
Auger Cover
1
28
891161
Weld., Bot. Plate Retainer
1
29
891195
Bracket, Drive Motor
1
30
891169
Hose, Heater
3 in
31
80488
Drive Motor
1
32
83529
Hairpin
1
33
86628
Weldment, Exhaust Duct
1
34
88117
Gasket, Exhaust Duct
1
35
80473
Blower, Exhaust
1
36
88100
Gasket, Exhaust Blower
1
37
80610
Thermodisc, POF - Low Limit
1
38
891987
Plastic Knob
1
39
69663
Damper Assembly
1
40
80619
Igniter Cartridge
1
41
86633
Weldment, Igniter Tube
1
42
88118
Gasket, Igniter Flange
1
43
80472
Blower, Distribution
1
44
88106
Gasket, Distribution Blower
1
45
80609
Thermodisc, Surface Mount, 210°
1
46
891187
Bracket, Pressure Switch/PCB
1
47
80621
Pressure Switch
1
48
89586
Nipple
1
49
891121
Silicone Tube
3 in.
50
83537
(#4) Hose Clamp
1
51
A-E-401GE Circuit Board (PCB)
1
52
891988
Cowl
1
53
88168
Gasket, Burnpot
1
N/S
80608
Wiring Harness (Main)
1
N/S = Not Shown
Key
Part No.
Description
Qty.
Key
Part No.
Description
Qty.
IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL
MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE
APPLIANCE MANUFACTURER.
USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.
