13 MDT-15K PARTS LIST
1 GS6675 Primary Gearset Assembly 1
2 GS46 Secondary Gearset Assembly 1
3 HMD15-20K-2SA Bail Assembly 1
4 S6-02 Output Housing 1
5 BS20J Bearing Shell 2
6 B20J Bearings 2
8 S3H Output Shaft 3” Hex STD 1
9 TC10x12 Seal 1
10 COR-06 Primary ‘O’ Ring 2
11 LK04 Lock Key 1
12 KM20 Lock Nut 1
14 RG6 Primary Ring Gear 1
15 IH6-4 Interim Housing 1
16 BS170 Secondary ‘O’ Ring 2
17 RG4 Secondary Ring Gear 1
18 S4-040 Input Housing 1
19 A2468-17T Spline Adaptor 1
20 B6012-1 Input Bearing 1
21 CWM51 Hydraulic Motor 1
22 P45 Bail Pin 1
23 SC01 Spring Clip 1
24 Segment Bolt 8
25 Hydraulic Motor Belt 4
26 Interim Bolt 8
27 Bail Bolt 8
28 CS-06 Shaft Circlip 1
29 Input Bolt 8
30 OP01 Oil Plug 2
31 KIT2SA Auto Kick Down Kit 1
Item Part No. Description No. Per
No Unit
