NHD110DRMicro Series Quick Installation Guide
www.ot-systems.com 4
(5) Operational Guides
5.1 Transmitter
LED Indicators
Indicator Colour Description
PWR Green Lit when power is supplied to the Transmitter.
SDI/HD
OFF SD signal input.
Green HD signal input.
SDI IN Green
Lit when SD-SDI or HD-SDI signal is fed into the SDI IN
connector.
DOUT Green Lit when output data is available at Tx
Signal Ports
OPT - ST Optical Connector for fiber cable connection.
SDI IN - BNC Video Connector for SD-SDI or HD-SDI signal input.
DATA - 7-pin Screw Terminal Block for data signal.
12V-
GND-
2-PIN Screw connector for 12VDC power input.
5.2 Receiver
LED Indicators
Indicator Colour Description
PWR Green Lit when power is supplied to the Receiver.
OL Green Lit when optical signal from receiver to transmitter is active.
SDI OUT Green
Lit when SD-SDI or HD-SDI signal is received at SDI OUT
connector.
DIN Green Lit when input data is available at Rx
Signal Ports
OPT - ST Optical Connector for fiber cable connection.
SDI OUT - BNC Video Connector for SD-SDI or HD-SDI signal output.
DATA - 7-pin Screw Terminal Block for data signal.
12V-
GND-
2-PIN Screw connector for 12VDC power input.
Manual Earth Green manual is available on our website www.ot-systems.com
