2. IMPORTANT OVERVIEW
11
2-3. Display Formats
Display Format modes Input Signal format Output Signal format
1080i all formats 1080i
720p all formats 720p
480p all formats 480p
480i all formats 480i
native 1080i 1080i
720p 720p
480p 480p
480i 480i(Component, DVI), 480p(RGB)
variable 1 1080i 1080i
720p 720p
480p/480i 480p
variable 2 1080i/720p 1080i
480p/480i 480p
variable 3 1080i/720p 720p
480p/480i 480p
DVI all formats changes according to monitor type
The DIRECTV ® HD Receiver provides several display formats. Pressing the DISPLAY
FORMAT button repeatedly on the front panel changes the display formats following order:
1080i
→ 720p → 480p → 480i → native → variable 1 → variable 2 → variable 3 → DVI. In
1080i, 720p, 480p, and 480i modes, all input signal formats are converted to the chosen dis-
play format. In native, variable 1, variable 2, and variable 3 modes, the output display for-
mat is automatically adapted depending on input signal format, as follows.
In DVI mode, the output display format is automatically adapted based on the preferred reso-
lution format of the DVI-HDTV monitor. The format may be converted from the original broad-
cast format.
Note : The DVI mode is only available when a DVI-HDTV compatible monitor is connected to
the receiver.
Note : Only one of the YPbPr, RGB or DVI-HDTV jacks is available at any one time, depending
on the TYPE switch setting and DVI-HDTV connection status.
