background image

Copyright © 2009 NEXCOM International Co., Ltd. All Rights Reserved.

75

Appendix C: VTCB6110 Carrier Board

VTC 6110 User Manual

Temp Sensor (JP8)

Pin

Function Description

1

SENSOR+

2

GND

Auto Power Select (JP2)

Pin

Status

Function Description

1-2 (default)

Short (default)

AUTO

2-3

Short

BUTTON CONTROL

PCI-104 VI/O Select Voltage (J13)

Pin

Status

Function Description

1-4(*)

Short*

+3.3V

3-6

Short

+5V

MCU Download (JP6)

Pin

Function Description

1

+V3.3ALW

2

C2D

3

MRST

4

C2CK

5

GND

GAL Download (JP5)

Pin

Function Description

1

+V3.3S

2

GND

3

TCK

4

TDO

5

TDI

6

TMS

MCU COM Port (JP3)

Pin

Function Description

1

TX

2

RX

3

GND
