5-2 Connectors Description
Connector Purpose Connector Purpose
CN2 COM5 Internal connector CN3 SATA 3 Connector
CN4 COM6 Internal connector CN5 SATA 3 Connector
CN6 MINI PCI-E CN7 Sim card holder
CN8 LVDS Connector 48 Bit CN9 LVDS Connector 48 Bit
CN10 Line-out & MIC CN11 Print port
CN12 COM4 Internal connector CN13 VGA Connector
CN14 DC-Power Input Connector
CON1 MSR connector CON2 Power output connector
CON3 USB+LAN Connector CON4 CASH drawing connector
CON5 SATA POWER Connector
J1 Internal USB connector J2 Internal USB connector
J4 Power on SW J5 Reset SW
J6 Battery socket J7 CCFL Connector
J8 Keyboard connector J9 Speaker OUT
J10 4/5 Wire touch connector
JP1 SATA/HD/LAN/POWER LED JP2 CMOS / ME Clear
JP4 Backlight voltage selection JP5 LCD Power selection
JP6 SDVO connector JP7 CASE OPEN Pin header
