- 6 -
oVerall and reCeSS diMenSionS
dimensions
Model
overall recess
height A Width B Depth C Height H Width W Depth D
RM2351
RM2354
inches
30-5/32 21-7/8 22-22/32 29-3/4 20-1/2 21-3/8
mm
766 556 577 756 521 542
RM2451
RM2454
inches
37-3/8 24-7/8 24-11/16 39-9/16 23-11/16 24
mm
948 632 627 928 602 610
RM2551
RM2554
inches
43-1/2 24-7/8 24-11/16 42-5/8 23-11/16 24
mm
1104 632 627 1083 602 610
DM2652
DM2662
DM2663
inches
54-21/32 24-7/8 26-1/32 53-3/4 23-11/16 24
mm 1388 632 661 1365 602 610
DM2852
DM2862
DM3862
inches
60-51/64 24-7/8 26-1/32 59-15/16 23-11/16 24
mm
1544 632 661 1522 602 610
NDM1062
inches
60-54/64 24-7/8 26-5/8 59-15/16 23-11/16 24*
mm
1544 632 676 1522 602 610*
NDR1292
inches
59-31/32 33-11/16 26-21/32 59-1/16 32-3/4 24*
mm
1523 855 677 1500 832 610*
Side view
$
( !
$
7
"
#
View from above
General view. Features may vary according to model.
* Add 1" (25 mm) depth for units with one or two optional ventilator fans.
Ventilation requirements
