Diasonic Tech DMP-105 User Manual
Page 25
Notice
When connecting it to exterior device turn the power off.
When connecting it to exterior device please carefully read and
understand the manual before the connection.
Record from Exterior Device
When recording from exterior device lower the volume of the
exterior device and connect audio cable to the product.
Adjust the volume of the product to mid-position and do not change
it during the record procedure.
Connecting it to Exterior Device
It's possible to record recorded voices from this product to exterior
device, such as cassette or MD using audio cable.
Connect to Audio
When recording exterior device to DMP-105/DMP-115 SERIES.
Connect additional audio cables to exterior microphone terminal
and earphone terminal from exterior device or the output terminal of
DMP-105/DMP-115 SERIES.
When recording DMP-105/DMP-115 SERIES
Connect additional audio cable to earphone terminal and
microphone terminal from exterior device of input of DMP-
105/DMP-115 SERIES.
Connecting method with an audio
