2
RF24-0001
INSTALLATION INSTRUCTIONS
1
Pre-drill holes and securely install the RF24 base (B) on para-
pet.
Use of expansion bolts (not included) is recommended when
installing into masonry surface.
2
Add pipe insert (L) into base, then secure in to position using
the included stainless steel bolts and washers.
3
Insert pipe extension (M) over insert, then secure in to position
using the included stainless steel bolts and washers.
