COMMELL LN-D70 User Manual
Page 28
LN-D70 User’s Manual
-
28
-
5 GND
6 SIMVPP
7 SIMDATA
Jumper:
JMSATA
Type: onboard 3-pin header
Note:SATA2-2 and mSATA can’t be enabled simultaneously
2.11.1
Step1.
SIM card holder is marked by circle.
Slide the cap toward OPEN direction.
MINI_CARD Mode
JMSATA
Supply mSATA
1-2
(Note)
MINI_CARD 2-3
Default setting: 2-3
