17 Page 34
Page 34
PMCA User’s Manual Hardware Setup
Expansion Interface
34
2.17
PMCA has one 16x and 1x PCI-Express slots .PCI-Express is the last expansion interface
technology, for its serial data transfer scheme, each lane will be up to 500MB/s (duplex),
and the 16x (16 lanes) can be up to 8GB/s more than 2GB/s as AGP 8x bus transfer rate.
The 16x slot can be also for 1x compatible use.
PCIE (PCI-Expres.s
16x
PCIE (PCI-Express
1x
slot)
