AS-C74 User’s Manual

Chapter1

1.1

AS-C74 is the motherboard with last Intel desktop technology with Mini-ITX form factor.
Based on Intel

Q67, the board integrates I3/I5/I7/Pentium/Xeon

processor 1155-pin

socket, DDR3 memory socket, Intel

HD Graphic technology, Serial ATA II with RAID

function for a powerful desktop system.

Intel® FCLGA1155 processor

The Intel

I3/I5/I7/Pentium/Xeon

processor now comes with a new form factor with

1155-pin FCLGA package, for 1066/1333MHz front-side-bus, 12MB L2 cache, for 65nm and

45nm manufacturing technology, the PLGA processor without pin header on solder side can

make user installing the processor on the socket easier.

Intel

Q67 PCH chipset

The Intel Q67 integrates DDR3 1066/1333MHz for memory, and HD Graphic technology for

new graphic engine. The Q67 integrates with up to 12 USB2.0 interfaces, and serial ATA II

interface with RAID function.

Flexible Extension Interface

The board provides one mini-PCIE socket, one mini-PCI socket, five PCI slots, one PCIE

X4 and one PCIE X16 slot.
