LE-370 User’s Manual Introduction
Product Overview
7
Chapter 1
1.1
LE-370/LE-370Z are the 3.5 inches embedded miniboards based on Intel 852GME/GM of
platform, with Intel Pentium M/Celeron M processors supported, onboard VGA, LAN,
Audio, USB2.0, CF, LVDS, and mini-PCI to meet the variable applications of users.
LE-370Z with onboard Intel Celeron M processor for ultra low power can offer the fanless
solution for such as medical applications.
Intel 852GME/GM & ICH4 Chipset
The board integrates Intel 852GME/GM and ICH4 chipset, to provide built-in Intel
Extreme Graphics Technology, and supports DDR200/266/333 memory up to 1G of
capacity.
18/24-bit LVDS LCD interface
The board provides onboard 18/24-bit LVDS LCD interface, supports up to 1600 x 1200
of UXGA high resolution for LE-370, and up to 1400 x 1050 for LE-370Z.
Flexible Extension Interfaces
The board provides one Mini-PCI socket for wireless LAN module, video capture card and
IEEE1394 add-on card. The board also provide optional PCI interface with a riser card to
have up to 2 PCI devices.
