LE-370 User’s Manual Introduction
Product Specification 9
LCD Interface
Chipset Intel 852GME/GM built-in LVDS interface
Interface 18/24-bit LVDS interface
12V backlight inverter connector
Ethernet Interface
Controller Intel 82562ET PHY
Type 10Base-T / 100Base-TX
auto-switching Fast Ethernet
Full duplex, IEEE802.3U compliant
Connector External RJ45 connectors with LED on rear I/O panel
Audio Interface
Chipset REALTEK ALC201A
Interface 2 channel 3D audio with Line-in, Line-out and MIC-in
Connector External Audio phone jack for Line-out
Onboard audio connector with pin header
Onboard CD-IN connector
Expansive Interface
Mini-PCI 1 x 32-bit 5V/3.3V Mini-PCI socket
PCI 1 x optional PCI interface supports up to two PCI devices through
riser card
Solid State Disk
DOM IDE1 supports 44-pin DOM (DiskOnModule)
CompactFlash 1 x CompactFlash Type 1 socket on solder side
Power and Environment
Power
Requirement DC 12V input
1 x DC jack on I/O panel or 1 x 4-pin DC connector onboard
Dimension 154 (L) x 101 (H) mm
Temperature Operating within 0 ~ 60
P
o
P
C (32 ~ 140
P
o
P
F)
Storage within -20 ~ 85
P
o
P
C (-4 ~ 185
P
o
P
F)
Software support
Operation
System Windows 98SE/ME, Windows 2000, Windows XP
Linux (
Fedora Core 1, Mandrake 9.2 and Red Hat 9.0)
Linux Kernel version 2.4 or later
Ordering Code
LE-370 Intel Pentium M/Celeron M with socket479, VGA, AC97 Audio,
LVDS, CF, PCI, Mini-PCI, 2 x RS232, LAN,
LE-370Z Same with above but with onboard Intel Celeron M 600 processor
1. The specifications may be different as the actual production.
For further product information please visit the website at
TU
http://www.commell.com.tw
UT
