16
Connector:
CN_INV
Type: 5-pin LVDS Power Header
Pin Description
1 +12V
2 PWM
3 GND
4 GND
5 ENABKL
Connector:
CN_LVDS
Type: onboard 40-pin connector for LVDS connector
Connector model: HIROSE DF13-40DP-1.25V or compatible
Pin Signal Pin Signal
2 LCDVCC 1 LCDVCC
4 LVDS Detect (Note) 3 GND
6 ATX0- 5 BTX0-
8 ATX0+ 7 BTX0+
10 GND 9 GND
12 ATX1- 11 BTX1-
14 ATX1+ 13 BTX1+
16 GND 15 GND
18 ATX2- 17 BTX2-
20 ATX2+ 19 BTX2+
22 GND 21 GND
24 ACLK- 23 BTX3-
26 ACLK+ 25 BTX3+
28 GND 27 GND
30 ATX3- 29 BCLK-
32 ATX3+ 31 BCLK+
34 GND 33 GND
36 DDCPCLK 35 N/C
38 DDCPDATA 37 N/C
40 N/C 39 N/C
Note: The LVDS Detect Pin please contact to the Panel GND.
To setup the LCD, you need the component below:
1. A panel with LVDS interfaces.
2. An inverter for panel’s backlight power.
3. A LCD cable and an inverter cable.
For the cables, please follow the pin assignment of the connector to make a cable, because
