FOREWORD
Delta Model 31-300 is an industrial/commercial duty 1-1/2 HP belt/disc sander. The induction-type, ball-bearing motor provides
long-lasting, smooth performance. The Sanding Center can provide 3000 SFPM with the belt, and the disc will revolve at 2100
RPM.
FUNCTIONAL DESCRIPTION
CARTON CONTENTS
1. Disc Sander Table
2. Belt Guard
3. #10-32 x
1 /
2
" Machine Screws (4)
4. Belt Sander Table
5. Motor
6. Knob (2)
7. Clamp (2)
8.
7 /
16
” Washer (2)
9. Spring (2)
10. Stud (2)
11. Handle (1)
12.
3 /
8
” Washer (1)
13. Tension Spring (1)
14.
3 /
8
” Hex Nut (1)
15. 3 /
8
” Lock Nut (1)
16. Stud (1)
1
2
3
4
5
Fig. 2
Fig. 3
