Desa BNG150T - Manual (Page 9)

9 103887
OWNER’S MANUAL
KEY PART
NO.
NUMBER DESCRIPTION QTY.
PARTS LIST
BNG150T
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 7 of this manual.
KEY PART
NO.
NUMBER DESCRIPTION QTY.
1 098511-114 Upper Shell 1
2 100647-01 Screw, #10-16 x 1/2" 8
3 098512-53 Combustion Chamber Kit 1
4 103891-01 Nozzle 1
5 103934-01 Ignitor 1
6 M11084-38 Screw, #8-18 x 3/8" 2
7 099334-03 Fuel Tube Kit 1
8 097806-02 Ignitor Cable 1
9 M51108-01 Heat Shield 1
10 M51153-01 Fan 1
11 103404-01 Motor 1
12 097776-01 Universal Bushing 1
13 078978-01 Sleeve Cap 1
14 103401-01 Male Connector 1
15 103403-01 Solenoid Valve 1
16 097966-12AA Base 1
17 M51605-02 DSI Control 1
18 M12461-7 Screw, #6-32 x 1" 2
19 099432-01 Hex Nut, #6-32 2
20 M11084-27 Screw, #10-16 x 1/2" 10
21 M50104-05 Shorty Bushing 1
22 M50104-01 Shorty Bushing 1
23 101481-05 Thermal Limit Switch 1
24 097968-05 Screw, #4-40 x 1/2" 2
25 097384-04 Hex Nut, #4-40 Captive Washer 2
26 098511-129 Lower Shell 1
27 097965-02AA Side Cover 1
28 098226-01 On/Off Switch 1
29 079010-38 Wire Assembly 1
30 103406-01 Regulator 1
31 M51104-01 Handle 1
32 M11084-29 Screw, #10-16 x 3/4" 2
33 097964-03AA Fan Guard 1
34 101206-01 Motor & Relay Support Brkt Assy 1
35 M11143-1 Strain Relief Bushing 1
36 098219-17 Power Cord 1
37 M50631 Rubber Bumper 2
38 NTC-4C Lock Nut 2
39 099157-01 Break Mandrell Rivet, 3/16" 1
40 099125-01 Terminal Board 1
41 M12461-25 Screw, #10-32 x 1/4" 2
42 103407-01 Fitting, Union 1/2 NPT to 1/2 NPT 1
43 M11271-8 Clip Nut 8
44 101480-10 High Temperature Wire Assy 1
45 101480-11 High Temperature Wire Assy 1
46 098276-01 Plug 1/8 NPTF Hex 1
47 M10908-1 Screw Hex TPG “F” 6-32 x .25 2
48 097657-03 Built-in Thermostat 1
49 104905-01 Thermostat Knob 1
50 103400-02 Screw, Baffle 1
51 078896-02 Washer, Baffle 1
079231-01 Service Center List 1
097940-09 Tradename Decal 2
103886-01 General Information Decal 1
099504-01 Warning Decal 2
103402-01 Wiring Decal 1
103021-01 Thermostat Decal 1
103889-01 NG Warning Decal 1
PARTS AVAILABLE—NOT SHOWN
