Kontrollknappens fjärrkontroll delas en på en fjärrkontroll,
(A, B, C eller D)
1. Med DIP-omkopplaren kan man ställa in (14) A till D på en
knapp på fjärrkontrollen:
DIP-omkopplaren är ej upptagen:
Kontrollknapp
fjärrkontroll
DIP-omkopplare fjärkontakt
A
B
C
D
E
A
ON
OFF
OFF
OFF
OFF
B
OFF
ON
OFF
OFF
OFF
C
OFF
OFF
ON
OFF
OFF
D
OFF
OFF
OFF
ON
OFF
2. Locket (18) viks inåt och stängs.
3. Sätt i och skruva fast skruvarna (16) genom skruvöppning-
arna (17) på spolen (15).
Exempel
Ställ in systemkod 123 genom fjärrkontroll .
Ställ in systemkoden 123 på alla fjärrkontakter. Ställ dessutom
in en fjärrkontakt. I figuren är knapp-paret A inställt med DIP-
omkopplare A:
32
Bruksanvisning
RCS 2044 N
