Atlona AT HD500 - Manual (Page 8)

8
Supported Resolutions
INPUT (VGA) 50 56 60 70 72 75/85
VESA: 640x480 X X X
800x600 X X X X
1024x768 X X X
1280x1024 X X
1600x1200 X
1280x800 X
1680x1050 X
1920x1200 X
OUTPUT (HDMI)
VESA: 640x480 X
800x600 X
1024x768 X
1280x1024 X
1600x1200 X
1280x800 X
1680x1050 X
1920x1200 X
VIDEO: 480i X
480p X
576i X
576p X
720p X X
1080i X X
1080p X X
Ports Inputs
1 x VGA
1 x 3.5mm audio
1 x optical audio
Outputs
1 x HDMI
1 x 3.5mm audio
1 x optical audio
Resolution Outputs VESA: up to 1920x1200
Video: up to 1080p
Dimensions (HxWxD) 0.98 x 3.94 x 6.06 (inch)
25 x 100 x 154 (mm)
Weight 0.75 lbs
0/34 kg
Operating Temperature 32°F to 118.4°F
0°C to 48°C
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
