Atlona AT HDTXRX ROADNET - Manual (Page 7)

7
Bandwidth 10.2Gbps
Ports
Video input
Video output
IR input
IR output
Firmware update
Power
AT-HDTX-ROADNET
1 x HDMI
1 x etherCON
1 x Mini USB
1 x 24V/2.7A
AT-HDRX-ROADNET
1 x etherCON
1 x HDMI
1 x Captive Screw
1 x Captive Screw
1 x Mini USB
Power Consumption 9.1W
Audio Passes up to Dolby TrueHD
or DTS-HD Master Audio
Resolution Video: up to 4Kx2K
VESA: up to 1920x1200
Distance Unstranded
328 feet
100 meters
Stranded
200 feet
60.96 meters
Dimensions 1.5 x 5 x 4 (inch)
38 x 127 x 102 (mm)
Weight 0.44 lbs
0.20 kg
Temperature Operating
32°F to 104°F
0°C to 40°C
Storage
-4°F to 140°F
20°C to 60°C
Certifications CE, FCC B, RoHS, cULus for power supplies
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
