Atlona AT HDWP Extenders - Manual (Page 11)

11
Bandwidth 10.2Gbps
Ports
A/V input
A/V output
IR input
IR output
Firmware update
AT-HDWP
1 x RJ45
1 x HDMI
1 x Mini USB
AT-HDWP-IR
1 x RJ45
1 x HDMI
1 x Captive Screw
1 x Captive Screw
1 x Mini USB
Power Consumption 8.7W (with AT-HDTX or AT-HDTX-IR)
Audio Passes up to Dolby TrueHD
or DTS-HD Master Audio
Resolution Video: up to 4Kx2K
VESA: up to 1920x1200
Distance 230ft @ 1080p over CAT6a/7
197ft @ 1080p over CAT5e/6
130ft @ 4Kx2K over CAT5e/6
Size 2 Gang
Installation Dimensions (H x W) 2.68 x 3.58 (inch)
Weight 0.49 lbs
0.22 kg
Temperature Operating
32°F to 104°F
0°C to 40°C
Storage
-4°F to 140°F
20°C to 60°C
Certifications CE, FCC, RoHS, cULus for power supplies
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
