RJ45 Define:
Link Cable (TIA/EIA-568-B )
No. Color Signal
1. Orange-white Video Pr+
2. Orange Video Pr-
3. Green-white Video Y+
4. Blue Audio -
5. Blue-white Audio +
6. Green Video Y-
7. Brown-white Video Pb+
8. Brown Video Pb-
AT-COMP300SL Switch Setting::
DIP Switcher Setting:
1
Audio Source Select
Stereo audio input (Analog)
Digital Audio input (Coaxial)
2 Analog Sampling Frequency
48Khz
44Khz
AT-COMP300SL LED indication:
Blue power on/off
Link Cable Connector:
Green: Digital audio signal setup
Yellow: Analog Sampling Frequency, ON = 48Khz, OFF = 44Khz
AT-COMP300RL Adjustment:
EQ equalization (sharpness)
Gain signal boost (brightness)
* Recommend to adjust the EQ trimmer to the right end, then slightly turn to left side for the best picture
quality. Improper adjustment can cause picture to become unstable, even resilting in no picture display.
AT-COMP300RL LED Indication:
Blue Power on/off
Link Cable Connector:
Green: Digital audio signal setup
Caution:
The cabling must remain away from any equipment with electromagnetic wave, i.e.: microwave, radio equip-
ment, high voltage lines.
