Series
Function
Feedback code
0704%
Switch to HDMI Input # 4
Source: DVI 4
0709%
Switch to VGA Input # 1
Source: VGA 1
0710%
Switch to VGA Input # 2
Source: VGA 2
0711%
Switch to VGA Input # 3
Source: VGA 3
0712%
Switch to VGA Input # 4
Source: VGA 4
0705%
Switch to Composite Video Input # 1
Source: CVIDEO 1
0706%
Switch to Composite Video Input # 2
Source: CVIDEO 2
0707%
Switch to Composite Video Input # 3
Source: CVIDEO 3
0708%
Switch to Composite Video Input # 4
Source: CVIDEO 4
0747%
Lock audio
LOCK VOICE OUT
0748%
Unlock audio input
UNLOCK VOICE OUT
0800%
Check the volume
DVI 1 Volume: XX (0~60)
DVI 2 Volume: XX (0~60)
DVI 3 Volume: XX (0~60)
DVI 4 Volume: XX (0~60)
AV 1 Volume: XX (0~60)
AV 2 Volume: XX (0~60)
AV 3 Volume: XX (0~60)
AV 4 Volume: XX (0~60)
VGA 1 Volume: XX (0~60)
VGA 2 Volume: XX (0~60)
VGA 3 Volume: XX (0~60)
VGA 4 Volume: XX (0~60)
MicVolume: XX (0~60)
0801%
Set Baud rate to 4800 bps
Baud rate: 4800
0802%
Set Baud rate to 9600 bps
Baud rate: 9600
0803%
Set Baud rate to 19200 bps
Baud rate: 19200
0804%
Set Baud rate to 38400 bps
Baud rate: 38400
0805%
Set Baud rate to 57600 bps
Baud rate: 57600
0806%
Set Baud rate to 115200 bps
Baud rate: 115200
/+1xxxx;
Send Command though RS232/485 Output which
will follow DVI/HDMI platform
232/485 DVI data: XXXXXXX
/+2xxxx;
Send Command though RS232/485 Output which
will follow Composite platform
232/485 AV data: XXXXXXX
/+3xxxx;
Send Command though RS232/485 Output which
will follow VGA platform
232/485 VGA data: XXXXXXX
/+0xxxx;
Send Direct Command though RS232/485 Output
232/485 Direct out data: XXXXXXX
0900%
Change all volume input mode
Change to output vol. control/Change to input
vol. control
