Atlona AT DRC444 R62011 - Manual (Page 4)

3 www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Video inputs 2 x DVI (DVI-D Only 24+1 Pin Female), 2 x HDMI (Type A female), 4 x VGA (HD15 female),
4 x Composite Video (BNC male)
Video outputs 1 x DVI (DVI-D Only 24+1 Pin Female) , 1 x VGA (HD15 female), 1 x Composite Video
(BNC male)
Video resolution DVI/HDMI up to 1920x1200 or 1080p;
VGA up to 3200x2400 @60Hz;
Composite Video: NTSC 3.58, NTSC 4.42, PAL, and SECAM
Video bandwidth DVI/HDMI: 340MHz (10.2Gbps);
VGA: 750MHz (-2.8dB) / Crosstalk ([email protected]) / 0.5V~2.0Vp-p;
Composite Video: 150MHz
Switching Speed 200ns
HDCP DVI/HDMI Inputs are HDCP Compliant
EDID/DDC VGA/HDMI/DVI Inputs are EDID/DDC compliant
Audio Inputs 12 Stereo line audio, 1 Mic
Audio Outputs 3 x Stereo unbalanced line audio and 1 x unbalanced programmed audio
Input Connectors 4 x 1/8-inch (3.5mm) – for VGA; 8 x Captive Screw connectors – for DVI/HDMI and
Composite and 1 x ¼-inch (6.3mm) – Mic
Audio Frequency 20Hz~20K Hz
CMRR >90dB @20Hz to 20K Hz
RS232 DB9 (2 = TX, 3 = RX, 5 = GND)
Power supply 100~ 240VAC, 50/60Hz
Power consumption 25W
Dimensions (inch) W19 x H1.73 x D9.25 - 1U
Dimensions (mm) W483 x H44 x D235 - 1U
Weight 4lb
Operating Temperature -20 o C ~ +70 o C
Operational Humidity 10% ~ 90%
SPECIFICATIONS
• 1 x AT-DRC444
• 1 x Power Cable
• 1 x IR Remote Control
• 1 x RS232 Cable
• 1 x Instructions Manual
PACKAGE CONTENT
