American Weigh Scales (AWS) Mini-Pro-50 - Manual (Page 6)

• Advanced Calibration (Linear):
You will need two weights to perform Advanced Calibration:
**MiniPRO-50 takes a 20g and a 50g weight.
**MiniPRO-100 takes a 50g and a 100g weight.
Press the “Menu” button one time, “SCALE” will be displayed
on the LCD; Press the “Units” button once to change to “LINE”
mode, then press “Tare” to confirm. The scale will display
the first required weight. Press “Tare” again to confirm. The
value will flash on the display. Place the first required weight
onto the weighing platform. In a few seconds, the display will
show the second required calibration weight. Add the second
weight to the platform. After a few more seconds, the weight
will be accepted and the scale will return to normal weighing.
Calibration is complete!
Model MiniPRO-50 MiniPRO-100
Capacity 50g / 1.7637oz / 1.6075ozt /
32.15dwt / 771.62gn / 250ct
100g / 3.5273oz / 3.2150ozt /
64.3dwt / 1543.25gn / 500ct
Resolution 0.001g / 0.0001oz / 0.0001ozt
/ 0.001dwt / 0.02gn / 0.005ct
0.002g / 0.0001oz / 0.0001ozt
/ 0.002dwt / 0.05gn / 0.01ct
Display
5 - Digit Backlit LCD
Calibration Weight
(not Included)
20g, 50g 50g, 100g
Platform Dimensions
(inches)
2.7” Diameter
Scale Dimensions
(inches)
5.2 x 3.7 x 2.3 ”
Power 4 x AAA Alkaline Batteries or
6V 100mA Adapter (included)
In a few seconds, the display will stop flashing, and return to
normal weighing. Calibration is complete!
