Parameter Setting:
Baud Rate: 9600
Data bit: 8
Parity Bit: Non parity
Stop Bit: 1
HDMI 8X1 RS232 Control Codes Version:1.0 Date:2008/2/5
Item Function Transmission Receiver
1 Power ON SETC10P31 RETC10P31
2. Power OFF SETC10P30 RETC10P30
3 Select Source SETC60S3xxx001
xxx is select source.
xxx = 001,002,….,008.
RETC60S3xxx001
xxx is select source.
xxx = 001,002,….,008.
4 Select Input Gain SETC70G31000xxx
xxx is input gain level.
xxx = 000,001,002.
RETC70G31000xxx
xxx is input gain level.
xxx = 000,001,002.
5 Select Output Gain SETC70G30000xxx
xxx is output gain level.
xxx = 000,001,002.
RETC70G30000xxx
xxx is output gain level.
xxx = 000,001,002.
6 Panel Lock SETC10L31 RETC10L31
7 Panel Unlock SETC10L30 RETC10L30
8 Get Power state SETC01P0 RETC11P2x
x is Power state.
0: Power off
1: Power on
9 Get Source state SETC01S0 RETC61S1xxx001
xxx is select source.
xxx = 001,002,….,008.
10 Get Input Gain level SETC11G01 RETC31G3xxx
