PARTS LIST
BURNER ASSEMBLY FOR MODELS
VC36N, VVC36N, VC36P, VVC36P, CGCDV36NR, CGCDV36PR
PARTS LIST
Models VC36N, VVC36N, VC36P, VVC36P, CGCDV36NR, CGCDV36PR
KEY PART
NO.
NUMBER
DESCRIPTION
QTY.
1
**
Burner Pan Assembly
1
2
**
Base Grate
1
3
**
Firebox Base Bottom
1
4
26808
Valve Bracket
1
5
11107
Screw, #10-32 x 1/4 Zinc
4
6
**
Firebox Bottom
1
7
11102
Screw, #8-32 x 3/8 Zinc
2
8
116344-01
Tubing Assembly
1
9
111288-02
Flex Gas Line
1
10
108084-02
Pilot Assembly (Natural Gas)
1
108084-03
Pilot Assembly (Propane/LP Gas)
1
11
14389
Natural Gas Valve
1
14390
Propane/LP Gas Valve
1
12
11165
Screw, #10 x 5/8 Zinc
23
13
111913-01
Burner Base Gasket
1
14
14396
Brass Fitting
2
15
116345-01
Pilot Bracket
1
16
26827
Switch Bracket
1
17
11226
Flat Washer 7/8" ID x 2" OD
2
18
11214
Bulkhead Fitting with Washer
2
19
14296
Elbow 3/8"
1
20
25520
Burner Orifice #37 (Natural Gas)
1
25238
Burner Orifice #52 (Propane/LP Gas)
1
21
14492
Piezo Ignitor
1
22
14511
Piezo Bracket
1
**Not a field replaceable part.
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 31 of this manual.
