www.desatech.com 111160-01C 37
PARTS LIST
THERMOSTATICALLY-CONTROLLED BILTMORE SPLIT OAK
MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 30 of this manual
KEY PART NUMBER
NO. CCL3018PTA CCL3018NTA DESCRIPTION QTY.
1 111340-03 111340-03 Front Log (#1) 1
2 111341-03 111341-03 Middle Log (#2) 1
3 111342-03 111342-03 Back Log (#3) 1
4 111343-03 111343-03 Left Back Crossover Log (#4) 1
5 111344-02 111344-02 Left Top Crossover Log (#5) 1
6 111345-02 11345-02 Right Bottom Crossover Log (#6) 1
7 ** ** Painted Base Assembly 1
8 102844-02 102844-02 Lower Bracket 1
9 099211-01 099211-01 Hex Screw, 10-16 x 2.50 2
10 098867-10 098867-14 Gas Regulator 1
11 102810-03 102810-03 Inlet Tube 1
12 102983-06 111331-08 Outlet Burner Tube 1
13 099056-19 099056-26 Burner Orifice Injector 1
14 111124-01 111124-01 Burner Retainer Spring 1
15 102980-01 102980-01 Burner 1
16 101329-22 101329-21 Thermostat Gas Valve Assembly 1
17 102979-02 102979-02 Thermostat Bracket 1
18 098544-01 098544-01 Thermostat Clip 1
19 102445-01 102445-01 Piezo Ignitor 1
20 099387-09 099387-09 Pilot Tube 1
21 098271-10 098271-10 Ignitor Cable 1
22 104286-01 104285-01 ODS Pilot 1
23 M11084-38 M11084-38 Hex Screw, #8-18 x .38 15
24 098249-01 098249-01 Nut, M5 2
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101054-01 101054-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100839-01 Caution Decal 1
101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 Lava Rock 1
** Not a field replaceable part.
