PARTS LIST
VARIABLE MANUALLY-CONTROLLED BILTMORE SPLIT OAK MODELS
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 30 of this manual.
KEY PART NUMBER
NO. CCL3018PA CCL3018NA CCL3924PA CCL3924NA DESCRIPTION QTY.
1 111342-03 111342-03 111342-02 111342-02 Back Log (#1) 1
2 111341-03 111341-03 111341-02 111341-02 Middle Log (#2) 1
3 111340-03 111340-03 111340-02 111340-02 Front Log (#3) 1
4 111343-03 111343-03 111343-02 111343-02 Left Back
Crossover Log (#4)
1
5 111344-02 111344-02 111344-01 111344-01 Left Top
Crossover Log (#5)
1
6 111345-02 111345-02 111345-02 111345-02 Right Bottom
Crossover Log (#6)
1
7 102844-02 102844-02 102844-01 102844-01 Lower Bracket 1
8 098867-10 098867-14 098867-10 098867-14 Gas Regulator 1
9 102798-01 102798-01 102798-01 102798-01 Inlet Tube 1
10 102779-04 102779-03 102779-02 102779-01 Outlet Burner Tube 1
11 099056-19 099056-26 099056-17 099056-16 Burner Orifice Injector 1
12 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1
13 102980-01 102980-01 102772-01 102772-01 Burner 1
14 102568-08 102568-07 102568-06 102568-05 Control Valve 1
15 098508-01 098508-01 098508-01 098508-01 Valve Retainer Nut 1
16 098354-01 098354-01 098354-01 098354-01 Control Knob 1
17 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1
18 099387-08 099387-08 099387-08 099387-08 Pilot Tube 1
19 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
20 104286-01 104285-01 104286-01 104285-01 ODS Pilot 1
21 M11084-38 M11084-38 M11084-38 M11084-38 Hex Screw, #8-18 x .38 8
22 098276-01 098276-01 098276-01 098276-01 Hex Head Plug, 1/8 NPT 1
23 098249-01 098249-01 098249-01 098249-01 Nut, M5 2
24 ** ** ** ** Painted Base Assembly 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
101055-02 101055-02 101055-02 101055-02 Lighting Instructions
Plate
1
100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 100639-01 Caution Decal 1
101449-04 101449-04 101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
** Not a field replaceable part.
