TOYOTA 2012 Yaris Hatchback - Manual (Page 258)

279
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
7 IGN 15 A
Multiport fuel injection system/
sequential multiport fuel injection
system
8 MET 7.5 A Gauges and meters
9 EPS 50 A Electric power steering system
10 ABS NO.2 30 A
Anti-lock brake system, vehicle sta-
bility control system
11 DEF 30 A
Rear window defogger, outside
rear view mirror defoggers
12 SPARE 10 A Spare fuse
13 PTC 80 A
PTC heater, outside rear view mir-
ror defoggers
14 HTR 40 A Air conditioning system
15 H-LP CLN 30 A No circuit
16 RDI FAN 30 A Electric cooling fan
17 ABS NO.1 50 A
Anti-lock brake system, vehicle sta-
bility control system
18 BBC 40 A No circuit
19 ST 30 A Starting system
20 AMP 15 A No circuit
21 D/L NO.2 25 A No circuit
22 D.C.C 30 A DOME, ECU-B NO.1, ECU-B NO.2
23 STR LOCK 20 A No circuit
24 ECU-B NO.1 5 A
Multiport fuel injection system/
sequential multiport fuel injection
system, main body ECU
25 DOME 15 A
Interior light, personal lights, audio
system, vehicle stability control
system
26 MIR-HTR 10 A No circuit
Fuse Ampere Circuit
