31
The radio does not work,
the radio station
automatic selection does
not work.
The antenna cable is not connected the
signals are too weak.
Insert the antenna cable firmly select a station
manually.
Specification
Specifications are subject to change without notice. Mass and dimension are approximate.
General
Power supply: 12 V DC
Current consumption/Fuse: max. 10 A/ 10 A
Maximum power output: 50 W x 4 channels
Dimensions (L x W x H): 218 x 83 x 285 mm
Working temperature range: -10º - +60º
FM Stereo Radio
Frequency range: 87.5 - 108.0 MHz
Usable sensitivity/ I.F. Frequency: 3 uV/ 10.7 MHz
Preset memory stations: 30
MW section
Frequency range: 522 kHz - 1620 kHz
Audio specification
Maximum output: 2 Vrms (+/- 3 dB)
Frequency response: 10 Hz to 20 KHz
S/N ratio(A-vtd): 50 dB
DSP sound effect: Classic, Rock, Pop, Flat
Line out
Output: CD max 2000 mV
