PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 23 of this manual.
PARTS LIST
Models CCL3924PR/PRA, CCL3924NR/NRA, CCL3930PR/PRA and CCL3930NR/NRA
KEY PART NUMBER
NO. CCL3924PR CCL3924PRA CCL3930PR CCL3930PRA
CCL3924NR CCL3924NRA CCL3930NR CCL3930NRA DESCRIPTION QTY.
1 105958-03 111340-02 105958-02 111340-01 Front Log (#1) 1
2 105959-03 111341-02 105959-02 111341-01 Middle Log (#2) 1
3 105960-03 111342-02 105960-02 111342-01 Back Log (#3) 1
4 105961-03 111343-02 105961-02 111343-01 Left Back Crossover Log (#4) 1
5 105962-03 111344-01 105962-03 111344-01 Left Top Crossover Log (#5) 1
6 105963-04 111345-02 105963-02 111345-01 Right Bottom Crossover Log (#6)
7 — — 105929-02 111346-01 Right Top Crossover Log (#7) 1
PART NUMBER
KEY CCL3924PR CCL3924NR CCL3930PR CCL3930NR
NO. CCL3924PRA CCL3924NRA CCL3930PRA CCL3930NRA DESCRIPTION QTY.
9 098249-01 098249-01 098249-01 098249-01 ODS Nut 2
10 098264-02 098264-02 098264-02 098264-02 Male Connector 1
11 111124-01 111124-01 111124-01 111124-01 Bur ner Retainer Spring 1
12 099056-17 099056-16 099056-17 099056-16 Burner Orifice Injector 1
13 103284-02 103284-02 103284-02 103284-02 Wiring Harness 1
14 102772-01 102772-01 102772-01 102772-01 Burner 1
15 099387-09 099387-12 099387-09 099387-12 Pilot Tube 1
16 103781-02 103781-01 103781-02 103781-01 Gas Control Valve 1
17 103345-01 103345-01 103345-01 103345-01 Lower Bracket 1
18 M11084-38 M11084-38 M11084-38 M11084-38 Screw, #8 x .38 7
19 02775-06CK 102775-06CK 102775-06CK 102775-06CK Painted Base Assembly 1
20 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
21 102445-01 102445-01 102445-01 102445-01 Piezo Ignitor 1
22 103587-02 103587-02 103587-02 103587-02 Plate, Switch 1
23 104099-01 104099-01 104099-01 104099-01 Heat Shield 1
24 098304-01 098304-01 098304-01 098304-01 Screw 2
25 103784-02 103784-02 103784-02 103784-02 Flame Adjustment Knob 1
26 103784-01 103784-01 103784-01 103784-01 Off-Pilot-On Knob 1
27 M12461-26 M12461-26 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
28
_____
100609-01
_____
100609-01 Pilot Tube (Regulator to Pilot) 1
29
_____
099918-02
_____
099918-02 Pilot Regulator 1
30 103342-02 103342-01 103342-02 103342-01 Burner Outlet Tube 1
31 099998-01 099998-01 099998-01 099998-01 Switch 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
103877-01 103877-01 103877-01 103877-01 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 100639-01 Caution Decal 1
101137-02 101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 GA6060 Lava Rock 1
