Dakota Digital LED Tail Lights LAT-NR101 User Manual

Lat-nr101

background image

MAN# 650195

INSTALLATION INSTRUCTIONS

LAT-NR101

LED Tail Lights for 1967-68 RS Camaro.

MAN# 650195

Kit includes:


Installation:

67-68 RS Camaro

1. Remove the original bulb sockets from the housing.

2. Remove the tail light housing hardware so the housing can be taken out of the car. Remove

the housings from the vehicle carefully so the body gaskets are not damaged.

3. Next remove the lens to gain access to the housing. There are six screws that hold the housing

halves together, remove the screws and separate the halves carefully.
