14
E
n
g
li
sh
3. Disconnect the spray wand from the gun.
Z
4. Remove the high-pressure nozzle from
the spray wand. Remove any obstructions
with the nozzle cleaning tool (Z) provided
and back flush with clean water.
5. Direct water supply into spray wand to
back flush loosened particles for 30
seconds.
6. Reassemble the nozzle to the wand.
7. Reconnect spray wand to gun then turn on water supply.
8. Start pressure washer and place spray wand into high pressure
setting to test.
To clean the Water Inlet Filter
This filter screen (U) should be checked
U
periodically and cleaned if necessary.
1. Remove the filter screen (U) by grasping
the end and removing it from water inlet of
pump.
. Clean filter by flushing it with water on both
sides.
3. Reinsert filter into water inlet of pump. Cone
side faces out.
note: Do not operate pressure washer without filter properly
installed.
To remove Tires
1. Using a 1/8" hex head wrench loosen set
screw in hub collar.
. Slide hub collar from axle and remove the
tire.
STorAGE
Engine
Consult the engine instruction manual for the manufacturer's
recommendations for storage.
Pump
The manufacturer recommends using a pump protector/winterizer,
such as DP80 when storing the unit for more than 30 days and/or
when freezing temperatures are expected. DP80 is availabe at the
store where the pressure washer was purchased. If a pump protector/
winterizer is not available, RV antifreeze or windshield washer fluid
needs to be run through the pump as outlined in the steps below.
note: Using a pump protector/ winterizer, RV antifreeze or wind-
shield washer fluid is to provide proper lubrication to the internal
seals of the pump regardless of temperature or environment.
1. Obtain a funnel, 6 oz. (17 ml) of RV antifreeze or windshield
washer fluid, and 16–36" (91 cm) of garden hose with a male
hose connector attached to one end.
cAutIoN: Risk of property damage. Use only Rv antifreeze. Any
other antifreeze is corrosive and can damage pump.
. Disconnect spark plug wire.
3. Connect length of garden hose to water inlet of pump.
4. Add RV antifreeze or windshield
washer fluid to hose as shown.
5. Pull engine starter rope slowly
several times until antifreeze/
washer fluid comes out of high-
pressure hose connection of
pump.
6. Remove garden hose from
water inlet of pump.
7. Reconnect spark plug wire.
