PARTS LIST
FIREPLACE MODELS
VTGF33NRB AND VTGF33PRB
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 31 of this manual.
KEY
NO. PART NO.
DESCRIPTION QTY.
1 101357-03 Top Outer Casing 1
101351-01CK Top Front 1
3 101353-01CK Middle Front Rail 1
4 111339-01 Blower Duct 1
5 ** Firebox Top 1
6 10171-03 Firebox Hood 1
7 10759-0CK Left Front Side 1
8 10758-0CK Right Front Side 1
9 M11084-6 Hex Screw, #10 60
10 09930-01 Shoulder Screw 4
11 ** Firebox Wrapper 1
1 101514-01 Cover 1
13 098304-01 Phillips Pan Head Screw, #10
14 ** Firebox Support
15 10455-18 Louver
16 104313-01 Hinge, Pin 1
17 104313-0 Hinge, Pin 1
18 M10908- Screw, Slotted Hex Head Tapping 4
19 098304-0 Phillips Pan Head Screw, 6-0 x .38 4
0 101346-01 Outer Base 1
1 10177-03 Screen Assembly 1
** Outer Casing 1
3 111547-01 Blower 1
PARTS AVAILABLE — NOT SHOWN
100639-01 Caution Decal 1
104356-0 Warning Decal 1
** Not a field replacement part.
