80 Series V
Users Manual
12
Table 5. Display Features (cont.)
Number Feature Indication
M A, μ A, mA
Amperes (amps), Microamp, Milliamp
V, mV
Volts, Millivolts
μ F, nF
Microfarad, Nanofarad
nS
Nanosiemens
%
Percent. Used for duty cycle
measurements.
e , Me, ke
Ohm, Megohm, Kilohm
Hz, kHz
Hertz, Kilohertz
AC DC
Alternating current, direct current
N ° C, ° F Degrees Celsius, Degrees Fahrenheit
O
610000 mV Displays selected range
P HiRes
The Meter is in high resolution
(Hi Res) mode. HiRes=19,999
Auto
The Meter is in autorange mode and
automatically selects the range with
the best resolution.
Q
Manual The Meter is in manual range mode.
Number Feature Indication
R
The number of segments is relative
to the full-scale value of the
selected range. In normal operation
0 (zero) is on the left. The polarity
indicator at the left of the graph
indicates the polarity of the input.
The graph does not operate with
the capacitance, frequency counter
functions, temperature, or peak min
max. For more information, see
“Bar Graph”. The bar graph also
has a zoom function, as described
under "Zoom Mode".
--
0L
Overload condition is detected.
Display Messages
bAtt Replace the battery immediately.
diSC
In the capacitance function, too much electrical
charge is present on the capacitor being tested.
EEPr Err Invalid EEPROM data. Have Meter serviced.
CAL Err Invalid calibration data. Calibrate Meter.
LEAd
W Test lead alert. Displayed when the test leads
are in the A or mA/ μ A terminal and the selected
rotary switch position does not correspond to the
terminal being used.
F8/Err Invalid model. Have Meter serviced.
OPEn Open thermocouple is detected.
