PARTS LIST
Models CLD3924NTA and CLD3924PTA
PARTS LIST
Thermostatically-Controlled Royal English
Oak Model
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 20 of this manual.
KEY PART NUMBER
NO. CLD3924NTA CLD3924PTA DESCRIPTION QTY.
1 109072-01 109072-01 Middle Log (#1) 1
2 109073-01 109073-01 Rear Log (#2) 1
3 109074-01 109074-01 Front Log (#3) 1
4 109075-01 109075-01 Crossover Log (#4) 1
5 102966-01 102966-01 Upper Bracket 1
6 098867-14 098867-10 Gas Regulator 1
7 102981-01 102981-01 Inlet Tube 1
8 102983-01 102983-01 Outlet Burner Tube 1
9 099056-16 099056-16 Burner Orifice Injector 1
10 102843-01 102843-01 Burner Clip 1
11 102772-01 102772-01 Burner 1
12 101329-20 101329-19 Thermostat Gas Valve Assembly 1
13 102979-01 102979-01 Thermostat Bracket 1
14 098544-01 098544-01 Thermobulb Clip 1
15 102445-01 102445-01 Piezo Ignitor 1
16 099387-09 099387-09 Pilot Tube 1
17 098271-07 098271-07 Ignitor Cable 1
18 104285-01 104286-01 ODS Pilot 1
19 M11084-38 M11084-38 Hex Screw, #8-18 x .38 15
20 098249-01 098249-01 Nut, M5 2
21 099211-01 099211-01 Hex Screw, 10-16 x 2.50 2
22 102775-05CK 102775-05CK Painted Base Assembly 1
23 102844-01 102844-01 Lower Bracket 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101054-01 101054-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 Caution Decal 1
101137-02 101137-02 Hardware Kit 1
108917-01 108917-01 Information Video 1
GA6060 GA6060 Lava Rock 1
