PARTS LIST
Models CLD3018NA and CLD3018PA
PARTS LIST
Variable Manually-Controlled Royal English
Oak Model
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 20 of this manual.
KEY
PART NUMBER
NO.
CLD3018NA
CLD3018PA
DESCRIPTION
QTY.
1
104933-02
104933-02
Middle Log (#1)
1
2
104934-02
104934-02
Back Log (#2)
1
3
104932-02
104932-02
Front Log (#3)
1
4
104935-02
104935-02
Crossover Log (#4)
1
5
102844-02
102844-02
Lower Bracket
1
6
102966-02
102966-01
Upper Bracket
1
7
098867-14
098867-10
Gas Regulator
1
8
102798-01
102798-01
Inlet Tube
1
9
102779-03
102779-01
Outlet Burner Tube
1
10
099056-26
099056-16
Burner Orifice Injector
1
11
102843-01
102843-01
Burner Clip
1
12
102980-01
102772-01
Burner
1
13
102568-07
102568-05
Control Valve
1
14
098508-01
098508-01
Valve Retainer Nut
1
15
098354-01
098354-01
Control Knob
1
16
102445-01
102445-01
Piezo Ignitor
1
17
099387-08
099387-08
Pilot Tube
1
18
098271-07
098271-07
Ignitor Cable
1
19
104285-01
104286-01
ODS Pilot
1
20
M11084-38
M11084-38
Screw, Hex Head (#8-18 x .38)
11
21
098276-01
098276-01
Hex Head Plug, 1/8" NPT
1
22
098249-01
098249-01
Nut, M5
2
23
102775-04CK
102775-01CK
Painted Base Assembly
1
PARTS AVAILABLE — NOT SHOWN
100563-01
100563-01
Warning Plate
1
101055-02
101055-02
Lighting Instructions Plate
1
100565-01
100565-01
Warning Plate Fastener
1
100639-01
100639-01
Caution Decal
1
101449-04
101449-04
Control Position Decal
1
101137-02
101137-02
Hardware Kit
1
108917-01
108917-01
Information Video
1
GA6060
GA6060
Lava Rock
1
