Vortech Ford 5.0L Maxflow Fuel Rails - Manual (Page 2)

FUEL LINE ATTACHMENT EXAMPLES:
EXAMPLE 1
EXAMPLE 2
© 1994 VORTECH ® ENGINEERING, INC.
all rights reserved
®
ENGINEERING, INC.
-6 AN UNION
O-RING
PASSENGER SIDE
FEED
DRIVER SIDE
®
-6 AN PLUG
-6 AN UNION
O-RING
PASSENGER SIDE
FEED
DRIVER SIDE
-6 AN PLUG
RETURN TO
FUEL TANK
®
FMU
VORTECH FUEL
REGULATOR
BLOCK
FUEL
REGULATOR
SUPER FMU
RETURN TO
FUEL TANK
FUEL RAIL INSTALLATION FORD 302/351 WINDSOR, cont'd.
