11
4.
FINAL ASSEMBLY
Fig. 4-a
Fig. 4-b
Fig. 4-c
A.
Reinstall the spare tire if equipped. (See Fig 4-a)
B.
Reinstall the rear tail light panel along with it's fas-
teners that were removed in an earlier step. (See
Fig 4-b)
C. Install the factory spare tire cover. ( See Fig 4-c)
D.
Reinstall the front core support cover. (See Fig
4-d)
Fig. 4-d
