1990-1995 5.0 & 5.7 Light Truck
Part No. 4GB218-050SQ
PARTS LIST
Part Number
Description
Quantity
4GB130-026
OIL FEED LINE ASSEMBLY
1
7U030-026
1/4” x 36” Oil Feed Hose
1
7P525-067
.500 Crimp Ferrules
2
7P250-066
#4 Swivel x 1/4” Hose Barb Fittings
2
7P250-036
#4 Flare to 1/4” NPT fitting
1
7P125-026
90
°
1/8” NPT x #4 Fitting
1
7P250-123
1/4” NPT x 1-1/2” Nipple
1
7P250-080
90
°
1/4” NPT Elbow
1
7U100-055
6” Nylon Tie Wraps
4
4GB130-036
OIL DRAIN ASSEMBLY
1
7R001-008
#8 Stainless Hose Clamps
2
7P375-017
3/8” NPT x 1/2” Straight Hose Barb
1
7U030-036
1/2” x 36” Oil Drain Hose
1
7P375-033
3/8” NPT x 3/8” NPT Street Elbow
1
4FA111-032
BELT TENSIONER ASSEMBLY
1
7J012-092
12mm Flat Washers
3
4FA011-032
Belt Tensioner
1
7C012-050
12mm x 1.75 x 50mm Bolt
1
4FA016-150
Smooth Pulley Tensioner
1
2A017-010
Idler Pulley Spacer
1
7C012-020
12mm x 1.75 x 20mm Bolts
2
7C012-022
12mm x 1.75 x 22mm Thin Head Bolt
1
7G010-175
12mm x 1.75 Nut
1
4GB101-002
FUEL PUMP ASSEMBLY
1
8F001-002
155 Inline Fuel Pump
1
7R003-024
1-1/2” Adel Clamp
1
5W001-011
16-14 GA Eyelet
1
5W001-001
Wire Tap
1
5W001-010
16-14 GA Insulated Female Slides
6
5W001-014
Fuse Holder
1
5W001-015
Blade Type 20A Fuse
1
5W001-017
Large Ring Terminal
1
8F101-200
T-Rex
®
Wiring Assembly
1
5W001-002
Fuse Tap
1
7R001-004
#4 Hose Clamps
2
7P625-001
Fuel adapter fitting
1
7U030-056
3/8” x 8” PCV Hose
1
7J010-001
#10 Flat Washers
4
7F010-032
10-32 Nylock Nut
2
7U100-055
6” Nylon Tie Wraps
4
7C011-075
10/32” x 3/4” Cap Screw
1
5W001-024
Mini Fuse Tap
2
5A001-004
FUEL INJECTION COMPUTER
1
Part Number
Description
Quantity
2E228-050
V-2 SUPERCHARGER ASSEMBLY
1
4GB111-021
MOUNTING BRACKET ASSEMBLY
1
4GB010-034
Mounting Plate
1
4GB011-021
Mounting Bracket
1
4GB015-014
Alternator Stay
1
7A375-375
3/8-16 x 3-3/4” Bolts
3
7A375-500
3/8-16 x 5” Bolts
2
7A375-350
3/8-16 x 3-1/2” Bolt
1
7F375-016
3/8-16 Nut
2
7K375-040
3/8” AN960 Flat Washers
10
7J375-044
3/8” SAE Washers
11
7A375-100
3/8-16 x 1” Bolts
10
4GG017-043
1/2" Spacer
2
7K3122-001
8mm Washers
2
7C080-025
8mm x 1.25 x 25 mm
2
4GB116-010
CRANK PULLEY ASSEMBLY
1
4GB016-011
Crank Pulley
1
4GB017-041
Crank Pulley Spacer
1
7B437-400
7/16-20 x 4” Bolt
1
7B375-275
3/8-24 x 2-3/4” Bolts
3
7J375-044
3/8” SAE Washers
3
7L375-075
3/8” Lock Washers
3
2A046-980
Belt
1
2A046-605
Belt
1
4GB112-010
AIR INTAKE ASSEMBLY
1
4GB012-010
Air Filter Cover
1
4GB012-012
Air Inlet Tube
1
4FA012-012
90
°
Intake Elbow
1
7P375-097
3/8” NPT x 3/8” Barb
1
7S350-200
3-1/2” x 2” Sleeves
2
4GB015-022
Air Inlet Tube
1
7E010-046
#8 x 3/4” Sheet Metal Screws
2
7U035-000
3-1/2” x 14” Flex Hose
1
8H040-040
Air Filter
1
7R002-056
#56 Hose Clamps
4
7R002-052
#52 Hose Clamps
3
7P375-017
3/8” NPT x 1/2” Straight Hose Barb
1
4GB112-020
AIR DISCHARGE ASSEMBLY
1
4GB012-020
Discharge Tube
1
4GB040-060
Air/Plenum Gasket
1
4GB050-011
Intake plenum
1
7P187-100
3/16" Hose Fitting
1
7R002-044
#44 Hose Clamps
4
7S275-200
2-3/4” x 2” Sleeve
1
7S275-300
2-3/4” x 3” Sleeve
1
7P750-102
3/4" NPT x 1" 90
°
Hose Fitting
1
7P750-100
3/4" NPT x 1" Straight Hose Fitting
1
7R002-016
#16 Hose Clamps
4
8D001-001
Bypass Valve
1
7U030-046
5/32" x 24" Vacuum Line
1
7P156-082
5/32" TEE
1
7U034-016
1" x 3" Heater Hose
1
7U034-016
1" x 8.0" Heater hose
1
8H040-075
1" Filter
1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report
any shortages or damaged parts immediately.
