Further Control Elements
OVERKILL
Connects FILTER Lancet to the AC-power-supply-unit. A green LED
shows an active powered unit.
ATTENTION:
The OVERKILL switch is no power switch. It simply
removes the connection to the power supply. Please do
always disconnect the PSU from the socket when not
using the unit for a longer period!
Connectors
Find a short description of the connectors on FILTER Lancet’s rear panel:
12 VAC
Connect the supplied AC power supply here.
INPUT
Input jack for the audio signal.
GATE
Input to trigger the envelope-follower. This input needs a voltage of 5
volts.
AUDIO TRIG
This audio input can trigger the envelope-generator.
PEDAL/CV
Allows connecting a CV-source or a pedal to control the CUTOFF-
frequency.
OUTPUT
Carries the output signal of FILTER Lancet to be connected to a mixing
console, an audio-interface or an amplifier.
