VMS User’s Manual
Specifications
Specifications VMS-8
Woofer 8” forward firing
(6.5” piston diameter)
Amplifier 2000 watts Dynamic
(Class D) 1000 watts RMS Power
High Pass Crossover 80 Hz (6 dB/octave)
Low Pass Crossover 40 Hz-120 Hz
12 dB octave initial,
48 dB octave ultimate
Frequency Response 26-120 Hz (+/-3 dB)
Harmonic Distortion <5% (typical)
Magnet Structure 204 oz.
(12.7 lbs)
Voice Coil 2.5” Dual Layer
inner/outer wind
Inputs Gold plated line-level and speaker-level
Outputs Line-level, 80 Hz up
Phase 0° or 180°
Video Shielded No
Dimensions (H/W/D) 10.063” x 10.375” x 12.75”
(inc. feet, grill and knobs) (27 x 26 x 33 cm)
Cabinet Sealed enclosure
Warranty Three years (electronics - parts and labor)
(parts/labor) Five years (drivers - parts and labor)
Shipping Weight (approx.) 35 lbs. (16 Kgs)
