Interconnect cables
When installing your new Velodyne subwoofer using the line level
connections, you should always use shielded phono cables. There are
many decent cables available today, most any of which will work
perfectly well. We do recommend that you keep the length of cable as
short as possible to avoid any potential noise problems.
When using speaker level connections, use a decent quality speaker cable
that mates well with the connectors. Be very careful to avoid any loose
strands or frayed wires which may result in a short, possibly causing
damage to your equipment. Cables of extremely large size are typically
not required. Extremely large gauge wire may not properly fit in the
binding posts, resulting in a poor connection and possible short circuits.
Figure 2: Installation using speaker-level (from amplifier) inputs
7
☞
INTEGRATED AMP / RECEIVER
MAIN OUTPUTS
(speaker-level)
SATELLITE SPEAKERS
