Specifications
16
.
w w w . v e l o d y n e . c o m
SPL-Ultra User’s Manual
NOTE: Specifications are subject to change
Model SPL-800 Ultra SPL-1000 Ultra SPL-1200 Ultra
Woofer: 8” forward firing 10” forward firing 12” forward firing
(6.5” piston diameter) (8” piston diameter) (9.7” piston diameter)
Amplifier: 2400 watts Dynamic 2400 watts Dynamic 2400 watts Dynamic
(Class D) 1200 watts RMS Power 1200 watts RMS Power 1200 watts RMS Power
High Pass Crossover: 80Hz (6 dB/octave) 80Hz (6 dB/octave) 80Hz (6 dB/octave)
Low Pass Crossover*: 40-135Hz 40-135Hz 40-135Hz
*12 dB octave initial, 24 dB octave ultimate
Frequency Response:
Overall 16-240Hz 13-240Hz 13-240Hz
(+/-3 dB) 26-135Hz 23-135Hz 21-135Hz
Harmonic Distortion: <5% (typical) <5% (typical) <5% (typical)
Magnet Structure: 204 oz. 346 oz. 346 oz.
(12.7 lbs) (21.6 lbs.) (21.6 lbs.)
Voice Coil: 2.5” Dual Layer 3” Dual Layer 3” Dual Layer
inner/outer wind inner/outer wind inner/outer wind
Inputs: Line and Speaker Level Line and Speaker Level Line and Speaker Level
Outputs: Line-level, 80Hz up Line-level, 80Hz up Line-level, 80Hz up
Phase: 0°, 90°, 180°, 270° degrees 0°, 90°, 180°, 270° degrees 0°, 90°, 180°, 270° degrees
Video Shielded: No Yes Yes
Dimensions (H/W/D): 11.2” x 10.7” x 14” 13.5” x 13” x 15.4” 15.5” x 15” x 18.5”
(inc. feet, grill and knobs) (28.4 x 27.2 x 35.6 cm) (34.3 x 33 x 39 cm) (39.4 x 38 x 47 cm)
Cabinet: Sealed enclosure Sealed enclosure Sealed enclosure
Finish: Hand-rubbed black lacquer Hand-rubbed black lacquer Hand-rubbed black lacquer
or cherry veneer or cherry veneer or cherry veneer
Accessories: Mic, mic stand, and Mic, mic stand, and Mic, mic stand, and
remote control remote control remote control
Warranty (parts/labor): Three years (electronics) Three years (electronics) Three years (electronics)
(North America) Five years (drivers) Five years (drivers) Five years (drivers)
Shipping Weight (approx.): 33 lbs. (15 Kg) 43 lbs. (20 Kg) 49 lbs. (22 Kg)
